ALU-Line SIDE GUSSET BAGS are the efficient, space-saving, form-stable packaging for individual parts, bulk goods, powder, granulates, pastes and liquids. Our aluminium composite film provides optimum protection against moisture, UV light, contamination and mechanical influences. Ströbel ALU-Line gusseted bags offer solid standing, shape stability, aroma preservation and an attractive appearance

Florian Meier Packaging Consultant

Susann Pliefke Team Corrosion Protection

Sebastian Schingale Team Corrosion Protection

Christine Hoffmann Team Corrosion Protection

CAPABILTIES OF ALU-Line SIDE GUSSET BAGS

Protection against

dust, dirt

uv light

spray water

loss of aroma

moisture

corrosion
with dessicants

temperature fluctuations

electrostatic discharge

Features

Corrosion protection
up to 10 years

aroma protection

food-certified

water vapour barrier

weldable

temperature resistant

printable

can be labelled

leakage barrier

puncture resistant

vacuum-capable / gas-tight

applications

parts

bulk material

granulate & powder

pasty goods

retail / POS

shipping

overseas transport

storage

long term storage

liquids

Ideal for

food products

pharma, medical

chemical industry

machine construction

metal construction

mould making

military, aviation, space travel

high-tech, technology

ESD electronics

very good very good good good moderate, conditional moderate, conditional no; not recommended no; not recommended
^{All info & data applies to optimal conditions.}

Types of side gusset bags

Our Ströbel experts are happy to advise you.

+49 (0)9101 99420

5-SEAM
Side gusseted bag

ideal for printing/labelling
valve option is possible
slightly lower internal volume

ENQUIRE NOW

BACK SEAM
Side gusseted bag

when side seams are unwanted
slightly more internal volume
backside with seam: difficult to print / label
valve option is not possible

ENQUIRE NOW

Standard sizes

IMMEDIATELY FROM STOCK

Shipping within 24 h

Our stock programme for ALU-Line SIDE GUSSET BAGS (5-seam) when things have to move fast - in white, silver, gold and black. The features include pressure relief valve and K-sealing.
All bags are unprinted and can be labelled.

FILM: ALU-Line "AROMA PRESERVATION" PET 12μ / AL 7μ / LDPE 100μ ⎮ Optimised for aroma preservation products. High quality protection.

Size	Outer dimensions	Carton contents	Colours
250g	100 + 65 x 265 mm	350 bags	white silver black gold
500g	117 + 65 x 340 mm	300 bags	white silver black gold
1.000g	142 + 75 x 420 mm	350 bags	white silver black gold

MANUFACTURED IN GERMANY

TAILOR-MADE

Shorter, longer, narrower, wider, more colourful... We will conjure up the perfect Ströbel ALU-Line SIDE GUSSET BAGS in your desired size, colour and print!
Precisely tailored to your application...

MADE IN BAVARIA, GERMANY

OPTIONS FOR ALU-Line SIDE GUSSET BAGS

rounded corners

stylish, round corners

valve

pressure relief valve for outgassing products or vacuum valve for vacuum drawing

k-sealing

better stability for gusseted bags, residue-free emptying

multicolour printing

Printing with 4C or up to 8 spot colours (minimum quantity)

hot stamping

cost-effective bag printing (partial, monochrome)

WHAT FITS TOGETHER?

5-SEAM OR BACK SEAM ?

Our production options depend on the type of gusseted bag.

	side gusset bags

	5 seams	rear seam
rounded corners
k-sealing
valve
hot stamping¹
multicolour printing

^{1) monochrome, different colours available}

GET IN TOUCH

+49 (0)9101 99 420

Contact

GET IN TOUCH

+49 (0)9101 99 420

Contact

FILM COLOUR

ALU-SILVER is our STANDARD.

YOUR CHOICE OF COLOUR
Aluminium composite film for ALU-Line SIDE GUSSET BAGS offers all conceivable colour possibilities. Special colours are available and subject to a minimum order quantity*.

* approx. >15.000 (dependent on bag size)

YOUR LOGO
AND PRINT

We give your ALU-Line SIDE GUSSET BAGS a unique outfit - according to your specifications. Our printing processes in 4c full colour or up to 8 spot colours are ideally suited for food packaging.

Our monochrome hot stamping printing technique is the ideal alternative for all savers. Ströbel ALU-Line SIDE GUSSET BAGS can of course also be labelled.

ENQUIRE NOW

ALU-Line FILM QUALITIES

ALU-Line "Premium" (AL+PE)

PET 12µm / AL 12µm / LDPE 75µm

our standard compound. Versatile.
High quality protection.

ALU-Line "aroma preservation"

PET 12µm / AL 7µm / LDPE 100µm

optimised for food aroma preservation packaging. High quality protection.

Other composites

other qualities and
thicknesses on request

TECHNICAL SPECIFICATIONS

Film	ALU-Line FILMS: Premium AL+PE & Aromaschutz Aluminium composite film; Look: Silver
Corrosion protection
Duration ^{Corrosion protection (up to)}	10 years with Ströbel topdry® dessicants
moisture protection
water vapour barrier
Aroma protection
_Protection How it works	Ströbel barrier layer film + Ströbel topdry® dessicants bind & neutralise corrosive humidity and thereby create a regulated protective atmosphere. Our aroma barrier preserves freshness and taste.
Manufacture ^Pouches

Thickness Bags	Premium: 100 µm Aromaschutz: about 120 µm
Layers Bags	_Premium: PET 12µm ⎮ AL 12µm ⎮ LDPE 75µm _Aromaschutz: PET 12µm ⎮ AL 7µm ⎮ LDPE 100µm
Other Qualities Bags	^{On request}
Temperature tolerance	_Premium: –40°C to +80°C _Aromaschutz: –40°C to +80°C
Water vapour transmission rate	_Premium: ≤ 0,05 to 0,1 g/m²/day _Aromaschutz: ≤ 0,1 g/m²/day
Puncture resistance	_Premium: ~ 68 N _Aromaschutz: On request
Standards	_Premium: TL 8135-0003, DIN 55 531, MIL_PRF-131-J, EU Regulation 1935/2004 & 10/2011 (food compliant) _Aromaschutz: EU Regulation 1935/2004 & 10/2011 (food compliant)

very good excellent good good moderate, conditional limited, depends no; not recommended no; not recommended

DOWNLOADS

Your Ströbel Downloads

OUR STRÖBEL ALU-LINE QUALITY PROMISE

"MADE IN FRANKONIA, GERMANY"

Our in-house production in Franconia, German and European standards, certifications, and suppliers from Germany and Europe stand for our Ströbel quality promise: reliable quality, transparent processes, and responsible production conditions. This reduces your risk from inferior protective films—and helps you avoid potential consequential damage to your valuable machines and products. Our ALU-Line SIDE GUSSET BAGS impress with stable and reliable barrier properties—based on clearly defined quality standards and regular, documented testing processes.

Yours sincerly,
Rainer Ströbel
