„ Our sensitive indicator uncovers transport violations at a low cost. Easily ensure that your product has been transported and stored upright according to your requirements. Our TILTWATCH PLUS has a tilt angle indicator that reveals positional changes from 40°- 80°. Also a rotation of 180° is indicated.... ”
Florian Meier Packaging Consultant
1
tilt axis
monitoring
above 40°
trigger value
yes
can be activated
when attaching
TECHNICAL DATA
|
triggering from 40° inclination |
| display: tilt direction | YES left / right |
| display: tilt angle | display: 30°, 40°, 50°, 60°, 70°, 80° for left and right; + rotation 180° (upside down position) |
| tolerance | ± 5° |
| operation | glass beads / pockets |
| can be activated? | YES with attachment |
| how often usable? | once |
| security | tamper-proof, consecutive serial number |
| mounting location on package | outside on package |
| mounting type | self-adhesive acrylic |
| operating range | temp: -40°C to 60°C; rel. humidity: 5% to 99% |
| shelf life | adhesive: 12 months (before application) |
| dimensions | 117 x 117 x 8 mm |
| PU | 50 pieces / carton |
INDICATION BEHAVIOUR
At an inclination of more than 40°, small glass balls roll from pocket to pocket and remain visible there; and this independently for both sides. A 180° head position indicator completes the display concept.
An individual serial number makes manipulation impossible. Transport violations are immediately visible and verifiable beyond doubt. Our TILTWATCH PLUS has a self-adhesive back for attaching to the packaging. However, it is also possible to screw, nail or staple it on.Matthias Mandel Vertriebsleiter
ADVANTAGES TILTWATCH PLUS
immediate display
potential damage is instantly indicated by shockwatch® label and logged at destination
up to 50% less transport damage
reduce the occurrence of transport damage in many cases by more than 50%.
avert damage claims
possible damage claims can be reduced or avoided.
easier claims settlement
damage settlement takes place mainly between the carrier and the recipient.
Increase the trust of your customers
customer satisfaction improves as it is ensured that the goods arrive intact.
CORRECT PLACEMENT AND ACTIVATION
TILTWATCH PLUS is attached to the outside of the package in a vertical position. The tilt indicator is self-adhesive and can be additionally fixed with staples or screws.
It is activated when the sticker is applied.
The measurement is single-axis. To monitor 2 tilt axes, 2 pieces of TILTWATCH PLUS must be mounted offset by 90°.
ACTIVATE
TILTWATCH PLUS are activated simply by peeling off the protective film when attaching.
ENQUIRE NOWThe freight process in 5 steps
How to integrate TILTWATCH PLUS into your shipping concept
STRÖBEL IMPORTANT INSTRUCTIONS
Be sure to share the following information with your clients:
PACKAGE CONTENTS
Quantity: 50 pieces / carton and each TILTWATCH PLUS unit consists of...
ACCESSORIES
